Key Features:
Performance Specifications:
20-hr.(250ma to 10.50 volts) .......... 5.0ah
10-hr.(4.50ma to 10.50 volts) .......... 4.50ah
5-hr. (7.50a to 10.20 volts) ........... 3.75ah
1-hr. (2.85a to 9.00 volts) ............. 2.85ah
15-min.(9.00a to 9.00 volts) ......... 2.25ah
1 Month ...... 97%
3 Months ..... 91%
6 Months ..... 83%
Charge ......... -4°F (-20°C) to 122°F (50°C)
Discharge ..... -40°F (-40°C) to 140°F (60°C)
Dimensions:
Height (Over Terminals): 4.21" (107)
Terminal/Connection Type:
Charging:
Cycle Applications: Limit initial current to 1.20a. Charge until battery voltage(under charge) reaches 14.4 to 14.7 volts at 68°F (20°C). Hold at 14.4 to 14.7 volts until current drops to under 350ma. Battery is fully charged under these conditions, and charger should be disconnected or switched to "float" voltage.
"Float" or "Stand-By" Service: Hold battery across constant voltage source of13.5 to 13.8 volts continuously. When held at this voltage, the battery will seek its own current level and maintain itself in a fully charged condition.
Note: Due to the self-discharge characteristics of this type of battery, it is imperative that they be charged within 6 months of storage, otherwise permanent loss of capacity might occur as a result of sulfation
